Maximum excavation distance | 13195mm |
Maximum digging depth | 8345mm |
Maximum vertical mining depth | 4705mm |
Maximum digging height | 12120mm |
Maximum unloding height | 8405mm |
Distance from the center of rotation to the rear end | 4010mm |
Minimum turning radius | 5730mm |
Minimum ground clearance | 850mm |
Maximum excavation force | 32.8/33.6kN |
Swing speed | 7.4rpm |
Maximum climbing force | 70° |
▲ The use of exclusive and efficient hydraulic control system,Engine:Cummins or German Main pump,Kawasaki or Rexroth optional control valve,Kawasaki or KYB optional walking motor,Doosan rotary motor high efficiency.
▲Has a strong traction force,and effectively prevent the soil and rock inclusion,to ensure that the work is more efficient.
▲High strength frame structure and larger ground clearance.
▲Open the engine hood safety,convenient maintenance(red and yellow colors).
