Whole Vehicle Parameters | Overall Length | 11700mm |
| Overall Width | 2550mm |
| Overall Height | 3950mm |
| Kerb Mass | 35000kg |
Boom & Leg Parameters | Vertical Boom Height | 47 m |
| Horizontal Boom Height | 42.6m |
| Vertical Boom Depth | 29.4m |
| Length /Turning Angle of Section 1 | 9500mm/89° |
| Length /Turning Angle of Section 2 | 7700/180° |
| Length /Turning Angle of Section 3 | 7550/180° |
| Length /Turning Angle of Section 4 | 8900/243° |
| Length /Turning Angle of Section 5 | 9000/214° |
| Boom Folding Type | 5RZ-Type |
| Turning Angle of Slewing Mechanism | ±360° |
| Span between Front Legs (mm) | 8500mm |
| Span between Rear Legs (mm) | 9400mm |
| Distance between Front and Rear Legs (mm) | 9000mm |
| Unfolding Mode of Legs | X |
Pumping System Parameters | Concrete Distribution Valve Type | S |
| Theoretical Concrete Pumping Capacity | 120m3/h;90m3/h |
